| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems AG6FCE |
| Series: | AG |
| Connector Type: | XLR |
| Gender: | Female |
| Housing Material: | Bronze, Zinc |
| Number of Contacts: | 6 |
| Mount Type: | Chassis Mount |
| Termination Method: | Solder |
| Contact Material: | Brass |
| Contact Plating: | Gold Over Silver |
| Maximum Operating Temperature: | 80 °C |
| Minimum Operating Temperature: | -30 °C |
| IP Rating: | IP00 |
| Mount Angle: | Straight |
| Housing Color: | Nickel |
| Mating Cycles: | 2000 cycle |
| Wire Size: | 28 AWG - 0.38 mm² |
| Flammability Rating: | UL 94V-HB |
| Current Rating: | 1.2 A |
| SKU: | AMEAG6FCE |
AG6FCE
Specifications
Detailed Description
Introducing the AG6FCE 6 Pole Mini XLR Chassis Mount Connector, designed for seamless audio, video, and broadcast connectivity. Featuring a G Type Female configuration with stamped contacts, this connector ensures reliable signal transmission. Its vertical PCB mount and rugged zinc bronze housing guarantee secure installation in any setup. With a contact plating of gold over silver, the AG6FCE offers optimal conductivity and durability, even in demanding environments. Operating efficiently between -30°C to 80°C, it's suitable for a wide range of applications. UL 94V-HB flammability rating and IP00 protection ensure safety and reliability. Backed by a 2000 cycle mating guarantee, this connector is built to last. With a current rating of 1.2A and wire size compatibility up to 28 AWG, the AG6FCE is a versatile choice for professional audio and video setups. Trust in its performance for seamless connectivity in any broadcast or AV system.
