| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems AT06-12SB-SS01 |
| Color: | Gray |
| Gender: | Female |
| IP Rating: | IP67 |
| Wire Size: | 20 - 14 AWG |
| Mating Cycles: | 100 cycle |
| Seal Material: | Silicone Rubber |
| Current Rating: | 13 A |
| Housing Material: | Plastic |
| Number of Contacts: | 12 |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Series: | AT |
| SKU: | AMEAT06-12SB-SS01 |
AT06-12SB-SS01
Specifications
Detailed Description
Introducing the AT Series™ Female 12-Contact Automotive Connector ( AT06-12SB-SS01), a versatile and reliable solution for your automotive connectivity needs. Designed for durability and performance, this connector features a rugged plastic housing in a sleek gray finish, perfect for seamlessly integrating into any automotive environment. With an IP67 rating and silicone rubber seals, it offers protection against dust, water, and other harsh elements, ensuring optimal performance even in challenging conditions. Its 12 gold-plated contacts allow for secure and efficient power and signal transmission, with a current rating of 13A. RoHS compliant and suitable for use with 20-14 AWG wire sizes, this connector is not only high-performing but also environmentally friendly. Whether you're working on a new vehicle design or upgrading existing systems, the AT Series™ Female 12-Contact Automotive Connector is the perfect choice for reliable and durable connectivity.
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 06/28/2021 | PCN-C1460S_REV_A - Appearance Change. in an effort to continuously improve our products we will change the slope of AT 12 pos plug housing latch, it will improve the insert and pull out hand feeling. this is a continual change so current and previous revisions of this part can be used interchangeably in the field this change is being phased in gradually. | Download | |||
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
