| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Aero-Electric Connector | Conesys |
| Manufacturer Part Number: | Aero-Electric Connector | Conesys MS3450KT20-22SW |
| Color: | Black |
| Series: | ATM |
| Gender: | Male |
| Housing Material: | Plastic |
| Number of Contacts: | 2 |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP67 |
| Seal Material: | Silicone Rubber |
| Mating Cycles: | 100 cycle |
| Wire Size: | 22 - 16 AWG, 22 - 20 AWG |
| Current Rating: | 7.5 A |
| SKU: | AMEATM04-2P-RB120BK |
MS3450KT20-22SW
Specifications
Detailed Description
Introducing the ATM Series™ Male Connector, MS3450KT20-22SW, designed for automotive applications. This black connector features a rugged plastic housing and two gold-plated contacts, ensuring reliable performance in harsh environments. With an IP67 rating and silicone rubber seals, it offers excellent water and dust resistance. Operating smoothly in temperatures ranging from -55°C to 125°C, it's ideal for use in a variety of conditions. The connector accommodates wire sizes from 22 to 16 AWG and 22 to 20 AWG, with a current rating of 7.5 A. Engineered for durability, it can withstand up to 100 mating cycles. While not RoHS compliant, its high-quality construction guarantees long-lasting connectivity. Perfect for automotive connectors and accessories, the ATM Series™ Male Connector sets the standard for reliability and performance.
