| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems C091 31C014 100 2 |
| Gender: | Male |
| Shielded: | Yes |
| IP Rating: | IP67 |
| Wire Size: | 24 AWG |
| Mount Type: | Panel Mount |
| Mating Type: | Screw |
| Mating Cycles: | 500 cycle |
| Current Rating: | 3 A |
| Voltage Rating: | 150 V |
| Contact Plating: | Silver |
| Housing Material: | Die-Cast Zinc |
| Number of Contacts: | 14 |
| Termination Method: | Solder |
| Maximum Operating Temperature: | 100 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | AMEC091 31C014 100 2 |
C091 31C014 100 2
Specifications
Detailed Description
The C091 31C014 100 2 is a rugged rear mounting male metal receptacle designed for demanding industrial applications. Constructed from durable die-cast zinc, this connector ensures reliable performance in harsh environments. With 14 contacts and a panel mount configuration, it offers secure and stable connectivity. The solder termination method and silver contact plating guarantee efficient signal transmission. Operating between -40°C and 100°C, and boasting an IP67 rating, it provides excellent resistance to temperature extremes and moisture ingress. Featuring a mating type of screw and capable of enduring 500 cycles, this shielded connector is built for longevity. Suitable for use with 24 AWG wire, it has a current rating of 3A and a voltage rating of 150V, making it ideal for power and signal applications. RoHS compliant and part of the Circular DIN Connectors range, the C091 31C014 100 2 is a high-quality solution for your connectivity needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
