| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems C091 31S003 100 2 |
| Gender: | Male |
| Housing Material: | Die-Cast Zinc |
| Number of Contacts: | 3 |
| Termination Method: | Solder |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 100 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP67 |
| Mating Type: | Screw |
| Mating Cycles: | 500 cycle |
| Shielded: | Yes |
| Wire Size: | 20 AWG |
| Current Rating: | 10 A |
| Voltage Rating: | 300 V |
| SKU: | AMEC091 31S003 100 2 |
C091 31S003 100 2
Specifications
Detailed Description
Introducing the FLANGE MOUNT MALE METAL RECEPT, a rugged and reliable circular DIN connector designed for demanding industrial environments. Constructed with high-quality Die Cast Zinc housing, this connector ensures durability and longevity. Featuring 3 silver-plated contacts for efficient signal transmission, it offers secure and solder termination. With an IP67 rating, it provides protection against dust and water ingress, making it suitable for outdoor use. The screw mating type allows for easy and secure connections, while the shielded design minimizes interference. Rated for 10A and 300V, it meets the requirements of high-power applications. With a wide operating temperature range of -40°C to 100°C and 500 mating cycles lifespan, it guarantees reliable performance. Perfect for use in aerospace, defense, and industrial applications.
