| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems C091 31W005 200 2 |
| Gender: | Male |
| Shielded: | Yes |
| IP Rating: | IP67 |
| Wire Size: | 20 AWG |
| Mount Type: | Panel Mount |
| Mating Type: | Screw |
| Mating Cycles: | 1000 cycle |
| Current Rating: | 7 A |
| Voltage Rating: | 300 V |
| Contact Plating: | Gold |
| Housing Material: | Die-Cast Zinc |
| Number of Contacts: | 5 |
| Termination Method: | Solder |
| Maximum Operating Temperature: | 100 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | AMEC091 31W005 200 2 |
C091 31W005 200 2
Specifications
Detailed Description
The C091 31W005 200 2 is a rugged and reliable Circular DIN Connector designed for front mounting on panels. With a housing made of durable Die Cast Zinc, this connector ensures secure connectivity in harsh environments. Featuring 5 gold-plated contacts, it offers excellent conductivity with a current rating of 7A and a voltage rating of 300V. The IP67 rating guarantees protection against dust and water ingress, making it ideal for outdoor or industrial applications. Its screw mating type allows for easy and secure connections, while the 1000 mating cycle durability ensures long-lasting performance. Termination is done via soldering, accommodating 20 AWG wire sizes. Designed for male gender, this connector is essential for professional-grade audio, video, and data transmission setups.
