| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems EP-3-12 |
| Series: | EP |
| Gender: | Male |
| Housing Material: | Die-Cast Zinc Alloy |
| Number of Contacts: | 3 |
| Termination Method: | Solder |
| Contact Material: | Brass |
| Contact Plating: | Bright Tin |
| Maximum Operating Temperature: | 75 °C |
| Minimum Operating Temperature: | -25 °C |
| IP Rating: | IP40 |
| Housing Color: | Nickel |
| Mating Cycles: | 1000 cycle |
| Wire Size: | 12 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 20 A |
| Voltage Rating: | 460 V |
| SKU: | AMEEP-3-12 |
EP-3-12
Specifications
Detailed Description
The EP-3-12, also known as the EP-3-12, is a robust and reliable 3 Pole Male Metal Loudspeaker Cable Connector designed for professional audio applications. Featuring machined Brass contacts with a Bright Tin plating, it ensures optimal signal transfer. The sturdy Die Cast Zinc Alloy housing, finished in Nickel, offers durability and protection, with an IP40 rating for dust resistance. Suitable for 12 AWG wire termination via soldering, this connector boasts a high current rating of 20 A and a voltage rating of 460 V, meeting rigorous industry standards. With a wide operating temperature range from -25°C to 75°C and a UL 94V-0 flammability rating, it guarantees performance in various environments. Perfect for loudspeaker systems, this RoHS-compliant connector is built to last, with a mating cycle of 1000 cycles. Trust the EP-3-12 for seamless audio connectivity in professional settings.
