| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems EP-4-13P |
| Series: | EP |
| Gender: | Male |
| Housing Material: | Die-Cast Zinc Alloy |
| Number of Contacts: | 4 |
| Mount Type: | Chassis Mount |
| Termination Method: | Solder |
| Contact Material: | Brass |
| Contact Plating: | Bright Tin |
| Maximum Operating Temperature: | 75 °C |
| Minimum Operating Temperature: | -25 °C |
| IP Rating: | IP40 |
| Housing Color: | Nickel |
| Mating Cycles: | 1000 cycle |
| Wire Size: | 12 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 20 A |
| Voltage Rating: | 660 V |
| SKU: | AMEEP-4-13P |
EP-4-13P
Specifications
Detailed Description
Introducing the EP-4-13P, a rugged and reliable 4 Pole Male Metal Loudspeaker Chassis Mount connector designed for professional audio applications. With machined contacts and a nickel finish, this connector ensures high-quality signal transmission. Its die-cast zinc alloy housing provides durability, while the solder termination method guarantees secure connections. Featuring a maximum operating temperature of 75°C and IP40 rating, it is suitable for various environments. The EP-4-13P is RoHS compliant and capable of handling 20A at 660V, making it ideal for high-power audio systems. With a UL 94V-0 flammability rating and 1000 mating cycles, this connector is built to last. Perfect for audio, video, and broadcast setups, the EP-4-13P sets the standard for performance and reliability in professional audio connectivity.
