| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems EP-5-12 |
| Series: | EP |
| Gender: | Male |
| Housing Material: | Die-Cast Zinc Alloy |
| Number of Contacts: | 5 |
| Termination Method: | Solder |
| Contact Material: | Brass |
| Contact Plating: | Bright Tin |
| Maximum Operating Temperature: | 75 °C |
| Minimum Operating Temperature: | -25 °C |
| IP Rating: | IP40 |
| Housing Color: | Nickel |
| Mating Cycles: | 1000 cycle |
| Wire Size: | 12 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 20 A |
| Voltage Rating: | 200 V |
| SKU: | AMEEP-5-12 |
EP-5-12
Specifications
Detailed Description
Introducing the EP-5-12, a robust 5 Pole Male Metal Loudspeaker Cable Connector designed for high-quality audio connections. Featuring machined contacts and a durable die-cast zinc alloy housing with a sleek nickel finish, this connector ensures reliable performance in any audio setup. With a solder termination method and bright tin contact plating, it offers secure and efficient conductivity. Operating temperature ranging from -25°C to 75°C, and an IP40 rating, guaranteeing durability in various environments. Ideal for loudspeaker applications, it can handle up to 20A of current at 200V. RoHS compliant and UL 94V-0 flammability rating, the EP-5-12 meets international standards for safety and environmental responsibility. Upgrade your audio connectivity with this premium connector from the EP series.
