| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems EP-5-13P |
| Series: | EP |
| Gender: | Female |
| Housing Material: | Die-Cast Zinc Alloy |
| Number of Contacts: | 5 |
| Mount Type: | Chassis Mount |
| Termination Method: | Solder |
| Contact Material: | Brass |
| Contact Plating: | Bright Tin |
| Maximum Operating Temperature: | 75 °C |
| Minimum Operating Temperature: | -25 °C |
| IP Rating: | IP40 |
| Housing Color: | Nickel |
| Mating Cycles: | 1000 cycle |
| Wire Size: | 12 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 20 A |
| Voltage Rating: | 200 V |
| SKU: | AMEEP-5-13P |
EP-5-13P
Specifications
Detailed Description
Introducing the EP-5-13P, a high-performance 5 Pole Female Metal Loudspeaker Chassis Mount connector designed for seamless audio connectivity. Featuring machined brass contacts with a durable nickel finish, this connector ensures reliable signal transmission. Its rugged die-cast zinc alloy housing and solder termination method guarantee secure installation, even in demanding environments. With a maximum operating temperature of 75°C and an IP40 rating, it offers durability and protection. Ideal for audio, video, and broadcast applications, the EP-5-13P is UL 94V-0 rated for enhanced safety. Boasting a current rating of 20A and voltage rating of 200V, it delivers exceptional performance. Trust the EP-5-13P for your loudspeaker connection needs.
