| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems EP-5-13PB |
| Series: | EP |
| Gender: | Female |
| Housing Material: | Die-Cast Zinc Alloy |
| Number of Contacts: | 5 |
| Mount Type: | Chassis Mount |
| Termination Method: | Solder |
| Contact Material: | Brass |
| Contact Plating: | Bright Tin |
| Maximum Operating Temperature: | 75 °C |
| Minimum Operating Temperature: | -25 °C |
| IP Rating: | IP40 |
| Housing Color: | Black |
| Mating Cycles: | 1000 cycle |
| Wire Size: | 12 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 20 A |
| Voltage Rating: | 200 V |
| SKU: | AMEEP-5-13PB |
EP-5-13PB
Specifications
Detailed Description
Introducing the EP-5-13PB, a 5 Pole Female Metal Loudspeaker Chassis Mount designed for seamless audio connectivity. Crafted with precision, this connector features machined contacts for optimal signal transmission. Its durable Die Cast Zinc Alloy housing in a sleek black finish ensures longevity and reliability. With a maximum operating temperature of 75°C and a minimum of -25°C, it guarantees performance in various environments. The Bright Tin plated brass contacts, suitable for 12 AWG wire termination via soldering, provide secure connections. Rated at 20 A and 200 V, this connector meets high standards for audio applications. With an IP40 rating for dust protection and UL 94V-0 flammability rating, it prioritizes safety. Ideal for audio, video, and broadcast setups, the EP-5-13PB is the perfect solution for professional sound systems.
