| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems EP-8-12B |
| Series: | EP |
| Gender: | Male |
| Housing Material: | Die-Cast Zinc Alloy |
| Number of Contacts: | 8 |
| Termination Method: | Solder |
| Contact Material: | Brass |
| Contact Plating: | Bright Tin |
| Maximum Operating Temperature: | 75 °C |
| Minimum Operating Temperature: | -25 °C |
| IP Rating: | IP40 |
| Housing Color: | Black |
| Mating Cycles: | 1000 cycle |
| Wire Size: | 14 AWG |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 15 A |
| Voltage Rating: | 100 V |
| SKU: | AMEEP-8-12B |
EP-8-12B
Specifications
Detailed Description
The EP-8-12B is a rugged and reliable 8 Pole Male Metal Loudspeaker Cable Connector designed for professional audio applications. Featuring machined Brass contacts with Bright Tin plating, this connector guarantees optimal signal transfer and durability. Its Die Cast Zinc Alloy housing in a sleek Black finish ensures both strength and style. With a wide operating temperature range of -25°C to 75°C and an IP40 rating for dust protection, it excels in demanding environments. Solder termination and 14 AWG wire size compatibility make installation easy, while its UL 94V-0 flammability rating ensures safety. With a current rating of 15A and voltage rating of 100V, this connector is perfect for high-power audio systems. Whether in live sound, recording studios, or broadcast setups, the EP-8-12B is the ideal choice for professionals seeking a high-performance audio connector.
