| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems T 3260 002 |
| Gender: | Male |
| Shielded: | Yes |
| IP Rating: | IP40 |
| Wire Size: | 20 AWG |
| Mount Type: | Cable Mount |
| Shell Size: | M16 |
| Mating Type: | Screw |
| Mount Angle: | Straight |
| Mating Cycles: | 500 cycle |
| Current Rating: | 10 A |
| Voltage Rating: | 250 V, 300 V |
| Contact Plating: | Silver |
| Housing Material: | Die-Cast Zinc |
| Number of Contacts: | 3 |
| Termination Method: | Solder |
| Maximum Operating Temperature: | 100 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | AMET 3260 002 |
T 3260 002
Specifications
Detailed Description
The T 3260 002 Male Cable Connector is a reliable and durable solution for your connectivity needs. Constructed with high-quality Die Cast Zinc housing material, this connector ensures robust performance in various applications. With three silver-plated contacts and a solder termination method, it guarantees secure and efficient signal transmission. Operating within a wide temperature range from -40°C to 100°C and boasting an IP40 rating for dust protection, it is suitable for use in demanding environments. The M16 shell size, straight mount angle, and screw mating type simplify installation. With a 500-cycle mating life and RoHS compliance, it meets industry standards for quality and reliability. Rated for 10A at 250V and 300V, with a wire size of 20 AWG, this connector is ideal for power and data applications. Upgrade your connectivity setup with the T 3260 002.
