| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems T 3262 000 |
| Gender: | Male |
| Shielded: | Yes |
| IP Rating: | IP40 |
| Wire Size: | 20 AWG |
| Mount Type: | Panel Mount |
| Mating Type: | Screw |
| Mating Cycles: | 500 cycle |
| Current Rating: | 10 A |
| Voltage Rating: | 300 V |
| Contact Plating: | Silver |
| Housing Material: | Die-Cast Zinc |
| Number of Contacts: | 3 |
| Termination Method: | Solder |
| Maximum Operating Temperature: | 100 °C |
| Minimum Operating Temperature: | -40 °C |
| Series: | C091 M16-A |
| SKU: | AMET 3262 000 |
T 3262 000
Specifications
Detailed Description
Introducing the T 3262 000, a robust FRONT MOUNTING MALE RECEPTACLE from the C091 M16-A series. Designed for demanding industrial environments, this connector features a durable Die Cast Zinc housing and is IP40 rated for protection against dust and moisture. With 3 silver-plated contacts, it ensures reliable signal transmission, while the solder termination method guarantees secure connections. Operating efficiently in temperatures ranging from -40°C to 100°C, this connector is suitable for a wide range of applications. Its panel mount design and screw mating type make installation easy, and with a maximum current rating of 10A and voltage rating of 300V, it meets high-performance standards. RoHS compliant and suitable for use with 20 AWG wire, the T 3262 000 is the ideal choice for your connectivity needs.
