| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems T 3262 100 |
| Series: | C091 M16-A |
| Gender: | Male |
| Housing Material: | Die-Cast Zinc |
| Number of Contacts: | 3 |
| Mount Type: | Panel Mount |
| Termination Method: | Solder |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 100 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP40 |
| Mating Type: | Screw |
| Mating Cycles: | 500 cycle |
| Shielded: | Yes |
| Wire Size: | 20 AWG |
| Current Rating: | 10 A |
| Voltage Rating: | 300 V |
| SKU: | AMET 3262 100 |
T 3262 100
Specifications
Detailed Description
The AMTT 3262 100 MALE RECEPT 3WAY REAT MT SLDR, part of the C091 M16-A series, is a robust and reliable circular connector designed for demanding industrial applications. Featuring a durable Die Cast Zinc housing with a shielded construction, this connector ensures secure and interference-free connections. With a panel mount design and solder termination method, installation is simple and efficient. Its three silver-plated contacts support a current rating of 10 A and a voltage rating of 300 V, making it suitable for power and signal transmission. Operating smoothly in temperatures ranging from -40°C to 100°C, and with an IP40 rating for dust protection, this connector offers dependable performance even in harsh environments. RoHS compliant and with a mating cycle of 500, the T3262100 is a high-quality solution for your connectivity needs.
