| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems T 3362 000 |
| Gender: | Male |
| Shielded: | Yes |
| IP Rating: | IP40 |
| Wire Size: | 20 AWG |
| Mount Type: | Panel Mount |
| Mating Type: | Screw |
| Mating Cycles: | 500 cycle |
| Current Rating: | 7 A |
| Voltage Rating: | 300 V |
| Contact Plating: | Silver |
| Housing Material: | Zinc Die Cast |
| Number of Contacts: | 5 |
| Termination Method: | Solder |
| Maximum Operating Temperature: | 100 °C |
| Minimum Operating Temperature: | -40 °C |
| Series: | C091 M16-A |
| SKU: | AMET 3362 000 |
T 3362 000
Specifications
Detailed Description
Introducing the T 3362 000, a rugged FRONT MOUNTING MALE RECEPTACLE designed for durability in demanding environments. Part of the C091 M16-A series, this connector features a zinc die-cast housing for robust protection. With five silver-plated contacts and a solder termination method, it ensures reliable conductivity. Operating in temperatures ranging from -40°C to 100°C, and with an IP40 rating for dust protection, it is suitable for a wide range of applications. The panel mount design, compatible with 20 AWG wire, is easy to install. Rated for 7A at 300V, it guarantees efficient power transmission. RoHS compliant and offering 500 mating cycles, this connector combines performance and longevity. Perfect for industrial, automotive, and telecommunications use, the T 3362 000 is the ideal choice for your connectivity needs.
