| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems T 3429 501 |
| Gender: | Male |
| Housing Material: | Die-Cast Zinc |
| Number of Contacts: | 6 |
| Mount Type: | Cable Mount |
| Termination Method: | Solder |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 100 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP40 |
| Shell Size: | M16 |
| Mating Type: | Bayonet |
| Mount Angle: | Straight |
| Mating Cycles: | 500 cycle |
| Shielded: | No |
| Wire Size: | 20 AWG |
| Current Rating: | 7 A |
| Voltage Rating: | 250 V, 300 V |
| SKU: | AMET 3429 501 |
T 3429 501
Specifications
Detailed Description
Introducing the T 3429 501 Male Cable Connector, a robust and reliable solution for your connectivity needs. Crafted from durable Die Cast Zinc, this connector features six contacts for seamless data and power transmission. With a cable mount design and solder termination method, installation is quick and easy. The silver contact plating ensures optimal conductivity, while the wide operating temperature range of -40°C to 100°C guarantees performance in any environment. Rated IP40 for dust protection, this M16 shell size connector is ideal for industrial applications. Its bayonet mating type and straight mount angle allow for secure connections. With a 500-cycle mating lifespan and 7A/250V current and voltage ratings, this connector offers long-lasting efficiency. Suitable for 20 AWG wire, it falls under the category of Circular DIN Connectors, making it a versatile choice for various projects. Upgrade your connectivity with the T 3429 501.
