1-282843-0

AMP1-282843-0
Heilind Number:AMP1-282843-0
Manufacturer:TE Connectivity
Manufacturer Number:1-282843-0
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

TERMI-BLOK PCB MOUNT 90 10P.

More >>

Specifications

AttributeValue
Product Category:
Connectors Terminal Blocks
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1-282843-0
Amperage:17.5 A
Gender:Header
Housing Material:PA 6/6
Number of Rows:1
Mount Type:Board Mount
Contact Material:Brass
Pitch:10.16 mm, .4 in
Voltage:600 V AC
Mount Angle:Straight
Block Type:Stacking w/interlock
Screw Size:M3
Package Quantity:50
Contact Amperage:17.5 A
Number of Positions:10
Housing Color:Green
GPL:124
Tail Length:.138 in, 3.5 mm
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Circuit Application:Power & Signal
Contact Mating Area Plating:Tin
GPL Description:Industrial
Connector and Contact Terminate To:Printed Circuit Board
Product Code:7742
Wire Size:.05 - 3 mm², 12 - 30 AWG
Connector System:Wire to Board
Screw Material:Brass
Stacking Configuration:Side Stackable
ECCN:EAR99
Screw Plating:Nickel
Entry Angle:Side
Interlock:With
Closed End:Without
Stacked Levels:Without
Threaded Flange:Without
Contact Mount Style:Through Hole
Marking Color:Black
Screw Flange:Without
Screwless Terminal Block:No
Wire Protection:With
Part Aliases:1-282843-0
SKU:AMP1-282843-0

Detailed Description

Enhance your PCB connections with the TERMI-BLOK 90 10P Terminal Block, designed for reliable power and signal transmission. This straight-mount block features a single row of 10 positions, accommodating wire sizes ranging from 12 to 30 AWG. With a current rating of 17.5 A and a voltage tolerance of 600 V AC, it ensures efficient performance in industrial settings. The PA 6/6 housing in a vibrant green color offers durability, while the brass contacts with tin plating provide secure connections. Meeting RoHS compliance, this connector system is suitable for wire-to-board applications, with a 10.16 mm pitch for easy installation on printed circuit boards. Operating in a wide temperature range from -40 to 110°C, it guarantees reliability in various environments. Whether for power distribution or signal routing, the TERMI-BLOK 90 10P is a versatile solution for your connectivity needs.
