160772-3

AMP160772-3
Heilind Number:AMP160772-3
Manufacturer:TE Connectivity
Manufacturer Number:160772-3
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

FASTON 110 REC 26-22 .009X.450 TPBR

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 160772-3
Series:FASTON 110
Contact Material:Brass
Contact Plating:Tin
Overall Length:14 mm, .551 in
Material:Brass
Compatible Tab Width:.11 in, 2.8 mm
Compatible Tab Thickness:.032 in, .81 mm
Terminal Type:Receptacle
Orientation:Straight
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Wire Size:.12 - .41 mm²
Crimp Type:F-Crimp
Barrel Type:Open
Accepts Wire Insulation Diameter:.035 - .063 in, .9 - 1.6 mm
Product:Quick Disconnects
Product Type:Receptacle
SKU:AMP160772-3

Detailed Description

Enhance your electrical connections with the FASTON 110 Receptacle. Designed for 26-22 AWG wires, this straight orientation terminal features a durable brass construction with tin plating, ensuring reliable performance. Its F-Crimp design allows for easy installation, accepting wire insulation diameters ranging from .035 to .063 inches. With an overall length of 14mm, it accommodates tabs with a width of .11 inches and thickness of .032 inches. Operating flawlessly in temperatures ranging from -40 to 110°C, this RoHS-compliant receptacle is a versatile solution for various applications. Upgrade your connectivity with this high-quality product from the Quick Disconnects line.
