170224-2

AMP170224-2
Heilind Number:AMP170224-2
Manufacturer:TE Connectivity
Manufacturer Number:170224-2
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

FASTON 250 REC 1.75 MM2 0.44 X 19.304

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 170224-2
Series:FASTON 250
Contact Material:Brass
Contact Plating:Tin
Overall Length:19.6 mm, .771 in
Material:Brass
Compatible Tab Width:.25 in, 6.35 mm
Compatible Tab Thickness:.032 in, .81 mm
Terminal Type:Receptacle
Orientation:Straight
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Wire Size:15 - 10 AWG, 1.65 - 5.26 mm²
Crimp Type:F-Crimp
Barrel Type:Open
Accepts Wire Insulation Diameter:.118 - .197 in, 3 - 5 mm
Product:Quick Disconnects
Product Type:Receptacle
SKU:AMP170224-2

Detailed Description

Enhance your electrical connections with our FASTON 250 receptacle, designed for seamless integration in a variety of applications. Crafted from durable brass with a tin plating, it ensures reliable conductivity and corrosion resistance. With a straight orientation and F-crimp type, it guarantees easy and secure installation for 15-10 AWG wire sizes. Its compatibility with 6.35mm tab widths and .81mm tab thicknesses offers versatility, while its open barrel design accommodates wire insulation diameters ranging from 3-5mm. Operating flawlessly in temperatures ranging from -40 to 110°C, it's a dependable choice for both professional and DIY projects. RoHS compliant and a part of our Quick Disconnects range, this receptacle meets high-quality standards for your peace of mind. Elevate your connector solutions with this essential component.
