1827395-1

AMP1827395-1
Heilind Number:AMP1827395-1
Manufacturer:TE Connectivity
Manufacturer Number:1827395-1
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

GIC 3.3 REC CONTACT TIN PLATE

More >>

Specifications

AttributeValue
Product Category:
Power Connectors Battery & Coin Cell Clips, Contacts & Holders
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 1827395-1
Series:GRACE INERTIA 3.3
Accessory Type:Contact
Mount Type:Cable Mount (Free-Hanging)
Termination Method:Crimp
Contact Material:Copper Alloy
Voltage:250 V AC, 250 V DC
Contact Type:Socket
Wire Type:Stranded
Package Quantity:5000
Cable Type:Discrete Wire
Contact Amperage:4 A
Termination Type:Crimp
Insulation Resistance:1000 MΩ
GPL:429
Packaging:Reel
Operating Temperature Range:-22 - 221 °F, -30 - 105 °C
Circuit Application:Power
Contact Mating Area Plating:Pre-Tin
GPL Description:Appliances
Connector and Contact Terminate To:Wire & Cable
Product Code:K756
Wire Size:20 - 24 AWG, .2 - .52 mm²
Connector System:Wire to Wire
Contact Termination Plating:Pre-Tin
ECCN:EAR99
Wire Insulation Support:Without
Accepts Wire Insulation Diameter:.059 - .0984 in, 1.5 - 2.5 mm
Contact Retention:With
Glow Wire Rating:Standard Part - Not Glow Wire
For Multiple Crimp:No
Contact Orientation:Straight
Wire Contact Termination Area Plating Material:Pre-Tin
Contact Retention Type in Housing:Locking Lance
Contact Product Type:Contact
Part Aliases:1827395-1
SKU:AMP1827395-1

Detailed Description

Enhance power connectivity with the GIC 3.3 REC CONTACT TIN PLATE, a vital component of the GRACE INERTIA 3.3 series. Designed for efficient cable mounting with a crimp termination method, this contact ensures reliable performance in various applications. Constructed from durable Copper Alloy, it offers a secure socket connection for 20-24 AWG stranded wires. With a contact amperage of 4A and a voltage rating of 250V AC/DC, it meets rigorous power transmission demands. Featuring pre-tin plating for enhanced conductivity and compatibility with wire to wire connectors, it guarantees seamless integration. With RoHS compliance and a wide operating temperature range of -30 to 105 °C (-22 to 221 °F), it's suitable for diverse industrial and appliance settings. Available in a package of 5000 on a convenient reel, this contact is essential for maintaining efficient power circuits.
