| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | TE Connectivity |
| Manufacturer Part Number: | TE Connectivity 2-1617806-4 |
| Amperage: | 10 A at 28 VDC, 115 VAC |
| Mount Type: | Raised Vertical Flange Mount |
| Operation Type: | Delay on Operate |
| Repeatability: | ±10% |
| Termination Type: | Solder Hook Terminal |
| Status Indicator: | None |
| Enclosure: | Hermetic Sealed Metallic |
| Dimensions: | 1.015 x 1.015 x 1 in, 25.79 x 25.79 x 25.4 mm |
| Contact Arrangement: | 2 Form C, DPDT, 2 C/O |
| Delay Time: | 300 seconds |
| Input Voltage: | 28 VDC |
| Control Type: | Fixed |
| SKU: | AMP2-1617806-4 |
2-1617806-4
| Heilind Number: | AMP2-1617806-4 |
| Manufacturer: | TE Connectivity |
| Manufacturer Number: | 2-1617806-4 |
| ECAD Model: | |
Specifications
Detailed Description
Experience seamless operation with our TD228-3003S Time Delay Relay, designed for precise timing in industrial applications. This relay offers a delay time of 300 seconds, ensuring optimal performance in delay on operate scenarios. With a contact arrangement of 2 Form C (DPDT), it provides reliable switching capabilities for critical systems. The amperage rating of 10 A at 28 VDC and 115 VAC guarantees robust power handling, while the hermetic sealed metallic enclosure ensures durability in harsh environments. Featuring solder hook terminals for easy installation, this relay is ideal for raised vertical flange mount setups. Trust in its ±10% repeatability and fixed control type for consistent operation. Please note, this product is not RoHS compliant. Elevate your control system with the TD228-3003S Time Delay Relay.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
