2007777-1

AMP2007777-1
Heilind Number:AMP2007777-1
Manufacturer:TE Connectivity
Manufacturer Number:2007777-1
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

IMP100S,H,V3P10C,LG,OEW39,4.5

More >>

Specifications

AttributeValue
Product Category:
Backplane Connectors & Accessories Backplane Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 2007777-1
Series:IMPACT
Amperage:.75 A
Connector Type:Header
Gender:Plug
Housing Material:LCP - GF (Liquid Crystal Polymer)
Number of Contacts:90
Number of Rows:9
Mount Type:Board Mount
Termination Method:Through Hole - Press-Fit
Contact Material:Copper Alloy
Contact Plating:Gold
Maximum Operating Temperature:185 °F, 85 °C
Body Orientation:Straight
Pitch:.075 in, 1.9 mm
Voltage:30 V AC, 30 V DC
Contact Type:Pin
Contact Length:.177 in, 25.5 mm, 4.5 mm
Row Spacing:.053 in, 1.35 mm
Impedance:100 Ω
PCB Hole Diameter:.015 in, .39 mm
Number of Pairs:30
Number of Positions:90
Data Rate:20 - 25 Gb/s
Housing Color:Black
Mount Orientation:Vertical
GPL:K74
Tail Length:.055 in, 1.4 mm
Packaging:Box & Tube, Tube
Operating Temperature Range:-55 - 85 °C, -67 - 185 °F
Circuit Application:Signal
Contact Mating Area Plating:Gold
Contact Mating Area Plating Thickness:29.92 µin, .76 µm
PCB Retention:With
Contact Underplating Material:Nickel
PCB Thickness (Recommended):1 mm
Connector Height:24.6 mm, .969 in
PCB Retention Type:Action/Compliant Tail & Screw
Sealable:No
Mating Alignment:With
Mating Alignment Type:Keyed
GPL Description:Data and Devices
Connector and Contact Terminate To:Printed Circuit Board
Product Code:L346
Number of Columns:10
Number of Signal Positions:60
Contact Design:Dual Beam
Contact Layout:Inline
Contact Transmits:Signal (Data)
Connector Length:1.004 in
Connector System:Board to Board
UL Agency Certification:E28476
Contact Termination Plating:Tin
Stackable:No
Connector Product Type:Connector
Pairs Per Column:3
Contact Style:Press-Fit
Board to Board Configuration:Right Angle, Vertical
Contact Underplating Thickness:1.27 µm, 50 µin
PCB Contact Termination Area Plating Finish:Matte
Connector Width:16.7 mm, .657 in
Mating Retention:Without
Make First / Break Last:No
Shroud Type:Partial
PCB Contact Termination Area Plating Thickness:30 - 60 µin, .76 - 1.52 µm
Guide Location:Left
Number of Ground Positions:30
End Wall Location:Open
Guide Hardware:Without
Signal Arrangement:Differential
Standards Met:Yes UL 94V-0
Material Flammability Standard:UL 94V-0
Part Aliases:2007777-1
SKU:AMP2007777-1

Detailed Description

Elevate your connectivity with the IMP100S Header Connector. Designed for high-speed signal transmission, this component boasts a robust construction with LCP - GF housing material and gold-plated copper alloy contacts. With a straight orientation and through-hole press-fit termination, it ensures secure and reliable board mount installation. Meeting UL 94V-0 standards, it guarantees safety and performance in demanding environments. Featuring 90 contacts in 9 rows, with a pitch of 1.9mm, it offers efficient data transfer at up to 25 Gb/s. Its black housing color and vertical mount orientation make it versatile for various applications. Whether in signal circuits or backplane connections, this connector excels in delivering optimal connectivity. Rest assured of its quality and compliance with RoHS standards, making it a sustainable and reliable choice for your electronic projects. Elevate your connectivity with the IMP100S Header Connector. Designed for high-speed signal transmission, this component boasts a robust construction with LCP - GF housing material and gold-plated copper alloy contacts. With a straight orientation and through-hole press-fit termination, it ensures secure and reliable board mount installation. Meeting UL 94V-0 standards, it guarantees safety and performance in demanding environments. Featuring 90 contacts in 9 rows, with a pitch of 1.9mm, it offers efficient data transfer at up to 25 Gb/s. Its black housing color and vertical mount orientation make it versatile for various applications. Whether in signal circuits or backplane connections, this connector excels in delivering optimal connectivity. Rest assured of its quality and compliance with RoHS standards, making it a sustainable and reliable choice for your electronic projects.
