| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | TE Connectivity |
| Manufacturer Part Number: | TE Connectivity 2041556-1 |
| Gender: | Receptacle |
| Housing Material: | Thermoplastic |
| Mount Type: | Board Mount |
| Termination Method: | Wave Solder |
| Pitch: | .098 in, 2.5 mm |
| Shell Plating: | Nickel |
| Number of Ports: | 1 |
| Orientation: | Vertical |
| USB Type: | A |
| USB Size: | Standard |
| USB Version: | 2.0 |
| Mount Location: | Top |
| Contact Amperage: | 1 A |
| Number of Positions: | 4 |
| Housing Color: | Black |
| Termination Type: | Through Hole |
| Tail Length: | .11 in, 2.8 mm |
| Operating Temperature Range: | -40 - 176 °F, -40 - 80 °C |
| Circuit Application: | Power & Signal |
| Contact Mating Area Plating: | Gold Flash over Palladium Nickel |
| Contact Mating Area Plating Thickness: | 29.92 µin, .76 µm |
| Mating Cycles: | 1500 |
| PCB Thickness (Recommended): | 1.6 mm |
| PCB Retention Type: | Straight Leg |
| Panel Mount Type: | Flange |
| Connector and Contact Terminate To: | Printed Circuit Board |
| Number of Mounting Legs: | 2 |
| Connector System: | Cable-to-Board |
| Connector Product Type: | Connector |
| LED Indicator: | Without |
| Locating Posts: | Without |
| Maximum Soldering Temperature: | 260 °C, 500 °F |
| Halogen Free: | No |
| Locking Feature: | Without |
| PCB Connector Seating: | Flush |
| Standard: | USB 2.0 |
| Material Flammability Standard: | UL 94V-0 |
| Part Aliases: | 2041556-1 |
| SKU: | AMP2041556-1 |
2041556-1
| Heilind Number: | AMP2041556-1 |
| Manufacturer: | TE Connectivity |
| Manufacturer Number: | 2041556-1 |
| Datasheet: | 3D Model (PDF) |
| ECAD Model: | |
Specifications
Detailed Description
Introducing a standard USB Type A receptacle, designed for vertical board mount installation with through-hole termination. Made of durable thermoplastic housing in black, this connector features a nickel shell plating and gold flash over palladium nickel contact mating area plating, ensuring reliable power and signal transmission. With a pitch of 2.5 mm and 4 positions, it is suitable for various electronic applications. Operating within a wide temperature range of -40 to 80 °C, it offers dependable performance. RoHS compliant and UL 94V-0 rated for flammability, this USB 2.0 connector is ideal for data and device connectivity in eco-friendly and safety-conscious designs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
