| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | TE Connectivity |
| Manufacturer Part Number: | TE Connectivity 204503-5 |
| Amperage: | 5 A |
| Gender: | Plug |
| Pitch: | .09 in, 2.29 mm |
| Shell Size: | 2 |
| Contact Size: | 22 |
| Number of Positions: | 26 |
| GPL: | 243 |
| Operating Temperature Range: | -22 - 257 °F, -50 - 125 °C |
| Circuit Application: | Signal |
| Sealable: | No |
| GPL Description: | Aerospace Defense & Marine |
| Connector and Contact Terminate To: | Wire & Cable |
| Product Code: | 4968 |
| Connector System: | Cable-to-Cable |
| Contact Style: | Crimp Snap-In |
| Non Magnetic: | Yes |
| Power Signal Coax Combination: | No |
| Blind Mate: | No |
| Part Aliases: | 204503-5 |
| SKU: | AMP204503-5 |
204503-5
Specifications
Detailed Description
Enhance your aerospace, defense, and marine applications with the AMPLIMITE 90° Plug Connector. Designed for signal circuitry, this high-performance connector features a 2.29mm pitch and 22 contact size, offering reliable connectivity in demanding environments. With a shell size of 2 and 26 positions, it ensures seamless integration in cable-to-cable setups. Operating efficiently in a wide temperature range from -50 to 125°C (-22 to 257°F), it's a durable solution for critical systems. ROHS compliant and featuring a non-magnetic design, it meets stringent industry standards. Experience seamless installation with the crimp snap-in contact style, ideal for wire and cable termination. Elevate your connectivity with this advanced connector, delivering power and signal integrity in a compact and efficient form factor.
For Use With
| Product | Part # | Description | Stock |
|---|---|---|---|
 | TE Connectivity 204370-2 |  |
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
