2108783-2

AMP2108783_2
Heilind Number:AMP2108783-2
Manufacturer:TE Connectivity
Manufacturer Number:2108783-2
Datasheet:2D Model (DXF)
ECAD Model:
3D Model

Description:

Chip Antenna, Multi Band, 5G / Cat-M/NB-IoT / Cellular, Internal/Embedded Mount, Surface Mount, Omnidirectional, Single Port, Gain 3 < 6 dBi

More >>

Specifications

AttributeValue
Product Category:
Passives Antennas
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 2108783-2
Impedance:50 Ω
Polarization:Linear
Protocol:EU Triband, LTE, UMTS, US Dual Band, WCDMA
Mounting Style:Surface Mount
VSWR:2:1
Antenna Type:Chip, PCB
Application:5G, Bluetooth, Cat-M/NB-IoT, Cellular, ISM, LoRaWAN, LPWA, Wi-Fi
Band Type:Multi Band
Center Frequency:1517.5 MHz, 2305 MHz, 3550 MHz, 768.5 MHz
Directionality:Omnidirectional
Frequency Range:1427 - 1608 MHz, 1710 - 2900 MHz, 3300 - 3800 MHz, 617 - 920 MHz
Gain:2.5 dB, 2 dB, 3.2 dB, 4.9 dB
SKU:AMP2108783-2

Detailed Description

Stay connected with our RoHS-compliant Multi Band Chip Antenna, designed for optimal performance in 5G, Cat-M/NB-IoT, and Cellular applications. This internal/embedded mount antenna features a surface mount design and omnidirectional coverage, perfect for seamless integration. With a gain ranging from 2 dB to 4.9 dB across multiple frequency bands, including 1427-1608 MHz and 3300-3800 MHz, it ensures reliable connectivity for LTE, UMTS, and more. Operating at a center frequency of 1517.5 MHz, 2305 MHz, 3550 MHz, and 768.5 MHz, it offers versatility for various wireless protocols. With linear polarization and a 50 Ω impedance, it guarantees efficient signal transmission. Ideal for IoT, LPWA, and Wi-Fi applications, this antenna is a must-have for high-performance wireless systems.
