2108784-2

Heilind Number:	AMP2108784-2
Manufacturer:	TE Connectivity
Manufacturer Number:	2108784-2
Datasheet:	Product Specification
ECAD Model:

Description:

Chip Antenna, Multi Band, 5G / Cat-M/NB-IoT / Cellular, Internal/Embedded Mount, Surface Mount, Omnidirectional, Single Port, Gain 3 < 6 dBi

More >>

Specifications

Attribute	Value
Product Category:	Passives Antennas
Manufacturer:	TE Connectivity
Manufacturer Part Number:	TE Connectivity 2108784-2
Impedance:	50 Ω
Polarization:	Linear
Protocol:	EU Triband, LTE, UMTS, US Dual Band, WCDMA
Mounting Style:	Surface Mount
VSWR:	3:1
Antenna Type:	Chip, PCB
Application:	5G, Bluetooth, Cat-M/NB-IoT, Cellular, GNSS, LoRaWAN, LPWA, Wi-Fi
Band Type:	Multi Band
Center Frequency:	1594.5 MHz, 2200 MHz, 3650 MHz, 4500 MHz, 5500 MHz, 829 MHz
Directionality:	Omnidirectional
Frequency Range:	1575 - 1614 MHz, 1710 - 2690 MHz, 3300 - 4000 MHz, 4000 - 5000 MHz, 5000 - 6000 MHz, 698 - 960 MHz
Gain:	1.93 dB, 2.3 dB, 3 dB, 4 dB, .98 dB
SKU:	AMP2108784-2

Detailed Description

Stay connected with our high-performance chip antenna, designed for seamless integration in a variety of electronic devices. With RoHS compliance and a range of gain options from 0.98 dB to 4 dB, this multi band antenna covers frequencies from 1575 MHz to 6000 MHz, including essential bands for 5G, Cat-M/NB-IoT, and cellular communication. Featuring omnidirectional coverage and linear polarization, it ensures reliable signal reception in any orientation. Ideal for applications such as Bluetooth, GNSS, and Wi-Fi, this surface mount antenna boasts a VSWR of 3:1 and impedance of 50 Ω, meeting the stringent requirements of LTE, UMTS, and other protocols. Elevate your connectivity with this compact yet powerful antenna solution.
