MS3456L22-20S

Heilind Number:	AMP2118900-1
Manufacturer:	Aero-Electric Connector \| Conesys
Manufacturer Number:	MS3456L22-20S
Datasheet:	3D Model (IGS)
ECAD Model:

Description:

PCB Antenna, Single Band, GNSS, Internal/Embedded Mount, Surface Mount, Omnidirectional, Gain 3 < 6 dBi

More >>

Specifications

Attribute	Value
Product Category:	Passives Antennas
Manufacturer:	Aero-Electric Connector \| Conesys
Manufacturer Part Number:	Aero-Electric Connector \| Conesys MS3456L22-20S
Impedance:	50 Ω
Polarization:	Linear
Protocol:	GPS
Mounting Style:	Surface Mount
VSWR:	2:1
Antenna Type:	PCB
Application:	GNSS
Band Type:	Single Band
Center Frequency:	1581 MHz
Directionality:	Omnidirectional
Frequency Range:	1560 - 1602 MHz
Gain:	3.5 dB
SKU:	AMP2118900-1

Detailed Description

Stay connected with reliable GPS signals using this ROHS-compliant PCB antenna. With a gain of 3.5 dB and a VSWR of 2:1, it ensures optimal performance in the 1560-1602 MHz frequency range, with a center frequency of 1581 MHz. Designed for internal/embedded mounting with a surface-mount style, this omnidirectional antenna offers seamless connectivity for GNSS applications. With a linear polarization and impedance of 50 Ω, it guarantees efficient signal reception. Perfect for a range of devices, this antenna falls under the Antennas, Passives, Products category, making it a versatile and essential component for your connectivity needs.
