2204273-2

Heilind Number:	AMP2204273-2
Manufacturer:	TE Connectivity
Manufacturer Number:	2204273-2
Datasheet:	Agency Approval Document (UL Report)
ECAD Model:

Description:

IN-LINE MOUNT 500A BUSBAR CONN.

More >>

Specifications

Attribute	Value
Product Category:	Power Connectors Busbar Connectors
Manufacturer:	TE Connectivity
Manufacturer Part Number:	TE Connectivity 2204273-2
Series:	Bowthorpe OCP2
Amperage:	500 A
Gender:	Receptacle
Housing Material:	Stainless Steel
Contact Material:	Copper Alloy
Contact Plating:	Silver Over Nickel
Voltage:	48 V AC
Contact Size:	2
Contact Amperage:	500 A
Number of Positions:	1
GPL:	K77
Packaging:	Box & Tray
Operating Temperature Range:	-55 - 105 °C
Circuit Application:	Power
Sealable:	No
Mating Alignment:	Yes
GPL Description:	Data and Devices
Connector and Contact Terminate To:	Bus Bar
Product Code:	1080
Contact Design:	Multiple Contact Point
Connector System:	Bus Bar-to-Bus Bar
ECCN:	EAR99
Contact Style:	Socket
PCB Mounting Style:	Through Hole - Screw
Part Aliases:	2204273-2
SKU:	AMP2204273-2

Detailed Description

Easily connect power systems with our In-Line Mount 500A Busbar Connector. Designed for high-performance applications, this connector features a stainless steel housing and copper alloy contacts with silver plating for optimal conductivity. With a voltage rating of 48V AC and an amperage of 500A, it ensures reliable power transmission. The contact design includes multiple contact points for secure connections, and the through-hole screw mounting style offers convenient installation. Operating in a wide temperature range from -55 to 105°C, it is suitable for various environments. RoHS compliant and lead-free solder process capable, this connector meets international quality standards. Perfect for industrial and commercial use, it is a dependable solution for power distribution.
