282826-4

Heilind Number:	AMP282826-4
Manufacturer:	TE Connectivity
Manufacturer Number:	282826-4
Datasheet:	Datasheet
ECAD Model:

Description:

TERMI-BLOK HEADER,ASSY90 4P.

More >>

Specifications

Attribute	Value
Product Category:	Pluggable Terminal Blocks & Headers Pluggable Terminal Block Headers
Manufacturer:	TE Connectivity
Manufacturer Part Number:	TE Connectivity 282826-4
Amperage:	15 A
Gender:	Header
Housing Material:	PA 6/6
Number of Contacts:	4
Number of Rows:	1
Mount Type:	Board Mount
Contact Material:	Copper Alloy
Pitch:	10 mm, .394 in
Voltage:	600 V AC
Mount Angle:	Vertical
Block Type:	None
Package Quantity:	100
Contact Amperage:	15 A
Number of Positions:	4
Housing Color:	Green
GPL:	124
Tail Length:	.138 in, 3.5 mm
Packaging:	Box
Operating Temperature Range:	-40 - 110 °C, -40 - 230 °F
Circuit Application:	Power & Signal
Contact Mating Area Plating:	Tin
GPL Description:	Industrial
Connector and Contact Terminate To:	Printed Circuit Board
Product Code:	7744
Wire Size:	.05 - 3 mm², 12 - 30 AWG
Connector System:	Wire to Board
ECCN:	EAR99
Header Type:	Shrouded
Interlock:	Without
Closed End:	With
Threaded Flange:	Without
Contact Mount Style:	Through Hole
Mating Angle:	180°
Screw Flange:	Without
Screwless Terminal Block:	No
Part Aliases:	282826-4
SKU:	AMP282826-4

Detailed Description

Introducing the TERMI-BLOK HEADER, ASSY90 4P, a versatile and durable board mount connector designed for power and signal applications. With a 15A amperage rating and 600V AC voltage capacity, this header assembly ensures reliable performance in industrial environments. Featuring a green PA 6/6 housing and copper alloy contacts with tin plating, it offers excellent conductivity and corrosion resistance. With a 10mm pitch and 4 contacts in a single row, it provides easy connectivity for 12-30 AWG wire sizes. Operating temperature range of -40 to 110°C (-40 to 230°F) and RoHS compliance guarantee safe and environmentally friendly use. Each package includes 100 units, making it perfect for large-scale projects. Whether for PCB assembly or wire-to-board connections, the TERMI-BLOK HEADER, ASSY90 4P is the ideal solution for your terminal block needs.
