63705-1

AMP63705-1
Heilind Number:AMP63705-1
Manufacturer:TE Connectivity
Manufacturer Number:63705-1
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

FASTON .125 RECEPTACLE 22-18 AWG BR

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 63705-1
Series:FASTON 125
Contact Material:Brass
Contact Plating:Unplated
Overall Length:16.13 mm, .635 in
Material:Brass
Compatible Tab Width:.125 in, 3.18 mm
Compatible Tab Thickness:.02 in, .51 mm
Terminal Type:Receptacle
Orientation:Straight
Operating Temperature Range:-40 - 110 °C, -40 - 230 °F
Wire Size:18 - 22 AWG, .32 - .82 mm²
Crimp Type:F-Crimp
Barrel Type:Open
Accepts Wire Insulation Diameter:.09 - .11 in, 2.3 - 2.8 mm
Product:Quick Disconnects
Product Type:Receptacle
SKU:AMP63705-1

Detailed Description

Enhance your electrical connections with these FASTON .125 Receptacles, designed for seamless integration with 22-18 AWG wires. Crafted from durable brass with unplated contact plating, these straight terminals ensure reliable performance in a wide temperature range from -40 to 110°C (-40 to 230°F). Featuring a .125-inch compatible tab width and accepting insulation diameters of .09 to .11 inches, they offer easy installation with F-Crimp technology. Trust in their quality, as they are RoHS compliant and part of our extensive range of crimp quick disconnect terminals. Upgrade your connectivity solutions today.
