6450830-1

AMP6450830-1
Heilind Number:AMP6450830-1
Manufacturer:TE Connectivity
Manufacturer Number:6450830-1
Datasheet:Statement of Compliance
ECAD Model:
3D Model

Description:

MBXL R/A HDR 2LP + 8S + 2LP

More >>

Specifications

AttributeValue
Product Category:
Connectors Power Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 6450830-1
Housing Material:High Temperature Thermoplastic
Number of Rows:4
Mount Type:Board Mount
Termination Method:Through Hole - Solder
Pitch:.115 in, .1 in, 2.54 mm, 2.92 mm
Voltage:60 V AC, 60 V DC
Contact Type:Pin
Row Spacing:.1 in, 2.54 mm
Contact Amperage:50 A
Number of Positions:12
Housing Color:Black
Mount Orientation:Right Angle
GPL:E79
Packaging:Tray
Operating Temperature Range:-40 - 125 °C, -40 - 257 °F
Circuit Application:Power & Signal
Contact Mating Area Plating:Noble Metal
Contact Mating Area Plating Thickness:.076 µm, 3 µin
PCB Retention:Without
Sealable:No
GPL Description:Data and Devices
Connector and Contact Terminate To:Printed Circuit Board
Product Code:L843
Number of Power Positions:4
Number of Signal Positions:8
Connector System:Board to Board
Contact Termination Plating:Tin
Connector Product Type:Header
ECCN:EAR99
Board to Board Configuration:Right Angle
Contact Underplating Thickness:4.45 µm
Termination Post Tail Length:.175 in, 4.45 mm
Contact Retention:Without
Glow Wire Rating:High Temperature Part - Not Glow Wire
Connector and Housing Type:Plug
Contact Material (Power):Tin
Material Flammability Standard:UL 94V-0
Part Aliases:6450830-1
SKU:AMP6450830-1

Detailed Description

Enhance your power and signal connectivity with our MBXL Right Angle Header. Featuring a durable High Temperature Thermoplastic construction, this connector boasts four rows of pins for seamless board mount installation. With a pitch of 2.54mm, it offers reliable termination through hole soldering, ensuring secure contact. Operating at temperatures ranging from -40 to 125°C, it's suitable for a variety of environments. With 12 positions, including four power and eight signal positions, it's ideal for high-performance applications. The UL 94V-0 flammability rating and RoHS compliance guarantee safety and environmental responsibility. Upgrade your power and signal transmission with this versatile connector.
