MS24265R20T39PN L/C

CIMMS24265R20T39PN L/C
Heilind Number:CIMMS24265R20T39PN L/C
Manufacturer:Cinch Connectivity Solutions
Manufacturer Number:MS24265R20T39PN L/C
ECAD Model:
3D Model

Specifications

AttributeValue
Product Category:
Circular Connectors & Accessories Circular MIL Spec Connectors
Manufacturer:Cinch Connectivity Solutions
Manufacturer Part Number:Cinch Connectivity Solutions MS24265R20T39PN L/C
Military Specification:MIL-C-26500
Series:Omega
Gender:Male
Housing Material:Aluminum
Number of Contacts:39 (37+2)
Mount Type:Panel Mount
Termination Method:Crimp
Maximum Operating Temperature:200 °C
Minimum Operating Temperature:-55 °C
Shell Size:20
Contact Type:Pin
Mating Type:Threaded
Seal Material:Fluorosilicone, Silicone Rubber
Shell Size - Insert Arrangement:20-39
Shell Material:Aluminum
Mating Cycles:200 cycle
Shell Type:Single Hole Mount Receptacle
Shell Finish:Anodized
Current Rating:13 A, 7.5 A
Voltage Rating:1500 VAC
Insert Arrangement:20-39
Locking Mechanism:Threaded
Operating Temperature:-55 to 200 °C
SKU:CIMMS24265R20T39PN L/C

Detailed Description

The Omega Series MIL-DTL-26500 Circular Connector, SKU CIMMS24265R20T39PNLC, is a rugged and reliable solution for military and aerospace applications. Designed for male gender, it features an aluminum housing with a panel mount for secure installation. With two contacts, this connector offers high-speed connectivity with a current rating of 13A and 7.5A. Operating in extreme temperatures from -55°C to 200°C, it ensures performance in harsh environments. The threaded mating type and silicone rubber and fluorosilicone seals provide a tight and durable connection, rated for 200 mating cycles. Finished with anodized coating, it offers corrosion resistance. Please note that this assembly does not ship with contacts, allowing for custom configurations. Meeting stringent military specifications, this hi-rel connector is a dependable choice for demanding applications.
