| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Hirose |
| Manufacturer Part Number: | Hirose DF13-2P-1.25V(76) |
| Series: | DF13 |
| Gender: | Male |
| Housing Material: | Nylon |
| Number of Contacts: | 2 |
| Number of Rows: | 1 |
| Mount Type: | Surface Mount |
| Termination Method: | Solder |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -35 °C |
| Pitch: | 1.25 mm |
| Mating Type: | Friction |
| Mount Angle: | Straight |
| Mating Cycles: | 50 cycle |
| Current Rating: | 1 A |
| Voltage Rating: | 150 VAC |
| SKU: | HIRDF13-2P-1.25V(76) |
DF13-2P-1.25V(76)
.jpg)
| Heilind Number: | HIRDF13-2P-1.25V(76) |
| Manufacturer: | Hirose |
| Manufacturer Number: | DF13-2P-1.25V(76) |
| ECAD Model: | |
Specifications
Detailed Description
Introducing our DF13 Series Male Connector, SKU DF13-2P-1.25V(76), designed to meet your board-to-board PCB connection needs with precision and reliability. Constructed with durable nylon housing and featuring two gold-plated brass contacts, this connector ensures optimal signal transmission even in demanding environments. With a pitch of 1.25mm and surface mount installation, it offers seamless integration onto your PCB. Operating efficiently in temperatures ranging from -35°C to 85°C and with a voltage rating of 150VAC, it provides dependable performance. The straight mount angle and friction mating type facilitate easy and secure connections. RoHS compliant and capable of enduring 50 mating cycles, this connector is both environmentally friendly and long-lasting. Ideal for applications requiring miniature and sub-miniature modular connectors, trust in the DF13 Series for high-quality connectivity solutions.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
