| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Industrial Operations |
| Manufacturer Part Number: | Amphenol Industrial Operations 97-3101A-14S-9PZ(959) |
| Pitch: | 1.25 mm |
| Gender: | Male |
| Mount Type: | Surface Mount |
| Mount Angle: | Right Angle |
| Number of Rows: | 1 |
| Voltage Rating: | 150 VAC |
| Contact Material: | Brass |
| Housing Material: | Nylon |
| Number of Contacts: | 2 |
| Termination Method: | Solder |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -35 °C |
| Series: | DF13 |
| SKU: | HIRDF13A-2P-1.25H(77) |
97-3101A-14S-9PZ(959)
.jpg)
| Heilind Number: | HIRDF13A-2P-1.25H(77) |
| Manufacturer: | Amphenol Industrial Operations |
| Manufacturer Number: | 97-3101A-14S-9PZ(959) |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the 97-3101A-14S-9PZ(959) male connector from the DF13 series, designed for reliable board-to-board PCB connectivity. With a housing made of durable nylon and two brass contacts, this surface-mount connector ensures secure solder termination. Its compact form factor, featuring a 1.25mm pitch and right-angle mount, is ideal for space-constrained applications. Operating efficiently in temperatures ranging from -35°C to 85°C and with a voltage rating of 150VAC, it guarantees performance in various environments. Perfect for miniature and sub-miniature modular connector setups, the DF13A2P125H77 offers high-quality connectivity for your electronic projects.
