| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Hirose |
| Manufacturer Part Number: | Hirose DF63M-1P-3.96DS |
| Color: | Black |
| Series: | DF63 |
| Gender: | Male |
| Housing Material: | Polybutylene Terephthalate |
| Number of Contacts: | 1 |
| Number of Rows: | 1 |
| Mount Type: | Through Hole |
| Termination Method: | Solder |
| Contact Material: | Brass |
| Contact Plating: | Tin |
| Maximum Operating Temperature: | 105 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 3.96 mm |
| Mount Angle: | Right Angle |
| Mating Cycles: | 30 cycle |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 15 A |
| Voltage Rating: | 630 VAC |
| SKU: | HIRDF63M-1P-3.96DS |
DF63M-1P-3.96DS
| Heilind Number: | HIRDF63M-1P-3.96DS |
| Manufacturer: | Hirose |
| Manufacturer Number: | DF63M-1P-3.96DS |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the DF63M-1P-3.96DS, a high-performance male connector designed for seamless board-to-board PCB integration. Crafted with durable Polybutylene Terephthalate housing material in sleek black, this connector ensures robust connectivity in any application. With a single contact and row, it offers easy installation through solder termination on a 3.96mm pitch. The brass contacts with tin plating guarantee reliable signal transmission, while its 630VAC voltage rating and 15A current rating make it suitable for power and data applications. Operating efficiently in temperatures ranging from -55°C to 105°C, it meets RoHS compliance and boasts a UL 94V-0 flammability rating for enhanced safety. Ideal for mezzanine and board stacking configurations, the DF63 connector is a versatile solution for your connectivity needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
