HR10A-7R-4PC(73)

HIRHR10A-7R-4PC(73)
Heilind Number:HIRHR10A-7R-4PC(73)
Manufacturer:Hirose
Manufacturer Number:HR10A-7R-4PC(73)
ECAD Model:
3D Model

Description:

110-0505-2-73 EACH

More >>

Specifications

AttributeValue
Product Category:
Circular Connectors & Accessories Circular Connectors
Manufacturer:Hirose
Manufacturer Part Number:Hirose HR10A-7R-4PC(73)
Gender:Male
Wire Size:30 - 26 AWG
Mount Type:Panel Mount
Shell Size:7
Mating Type:Push-Pull
Mount Angle:Straight
Shell Finish:Nickel
Mating Cycles:1000 cycle
Current Rating:2 A
Voltage Rating:150 VAC
Contact Plating:Silver
Housing Material:Metal
Number of Contacts:4
Termination Method:Crimp
Maximum Operating Temperature:85 °C
Minimum Operating Temperature:-25 °C
Shell Size - Insert Arrangement:7-4
Series:HR10
SKU:HIRHR10A-7R-4PC(73)

Detailed Description

Introducing the HR10A-7R-4PC(73), a high-performance circular connector designed for male gender applications. Crafted with durable metal housing and featuring 4 silver-plated contacts, this panel-mount connector ensures reliable signal transmission in various environments. With a wide operating temperature range from -25°C to 85°C, it is suitable for use in both extreme cold and hot conditions. The straight mount angle and push-pull mating type make installation and disconnection quick and hassle-free. Meeting RoHS compliance standards, this connector guarantees environmental responsibility. Ideal for hi-rel applications, it offers a voltage rating of 150 VAC and a current rating of 2A, accommodating wire sizes ranging from 30 to 26 AWG. With a shell finish of nickel and a mating cycle durability of 1000 cycles, the HR10A-7R-4PC(73) is a reliable solution for demanding connectivity needs.
