HR212-10RA-8SDL(74)

HIRHR212-10RA-8SDL(74)
Heilind Number:HIRHR212-10RA-8SDL(74)
Manufacturer:Hirose
Manufacturer Number:HR212-10RA-8SDL(74)
ECAD Model:
3D Model

Description:

112-2004-0-74 EACH

More >>

Specifications

AttributeValue
Product Category:
Circular Connectors & Accessories Circular Connectors
Manufacturer:Hirose
Manufacturer Part Number:Hirose HR212-10RA-8SDL(74)
Gender:Female
Mount Type:Through Hole
Shell Size:10
Mating Type:Snap-On
Mount Angle:Right Angle
Mating Cycles:1000 cycle
Current Rating:2 A
Voltage Rating:100 VAC
Contact Plating:Tin
Housing Material:Plastic
Number of Contacts:8
Termination Method:DIP
Maximum Operating Temperature:60 °C
Minimum Operating Temperature:-15 °C
Shell Size - Insert Arrangement:10-8
Series:HR12
SKU:HIRHR212-10RA-8SDL(74)

Detailed Description

Introducing the HR212-10RA-8SDL(74), a high-performance circular connector designed for female gender applications. Crafted with durable plastic housing, this connector features 8 tin-plated contacts for reliable conductivity. With a through-hole mount type and DIP termination method, installation is secure and straightforward. Operating efficiently in temperatures ranging from -15°C to 60°C, it's suitable for a variety of environments. The snap-on mating type and right-angle mount angle offer convenience in assembly. With a shell size of 10 and a current rating of 2A, it guarantees optimal performance. Certified RoHS compliant and rated for 100VAC, this connector is not only efficient but also environmentally friendly. Ideal for aerospace, defense, and industrial applications, the HR12 series ensures quality and durability with a mating cycle of 1000 cycles. Upgrade your connectivity with the HR212-10RA-8SDL(74) circular connector.
