HR30-6P-6P(31)

HIRHR30-6P-6P(31)
Heilind Number:HIRHR30-6P-6P(31)
Manufacturer:Hirose
Manufacturer Number:HR30-6P-6P(31)
ECAD Model:
3D Model

Description:

130-0009-5-31 EACH

More >>

Specifications

AttributeValue
Product Category:
Circular Connectors & Accessories Circular Connectors
Manufacturer:Hirose
Manufacturer Part Number:Hirose HR30-6P-6P(31)
Series:HR30
Gender:Male
Housing Material:Plastic
Number of Contacts:6
Mount Type:Panel Mount
Termination Method:Solder
Contact Plating:Gold
Maximum Operating Temperature:85 °C
Minimum Operating Temperature:-25 °C
IP Rating:IPX8
Shell Size:6
Mating Type:Push-Pull
Mount Angle:Straight
Seal Material:Chloroprene, Silicone Rubber
Shell Size - Insert Arrangement:6-6
Mating Cycles:1000 cycle
Wire Size:4.5 - 5 mm
Current Rating:2 A
Voltage Rating:100 VAC
SKU:HIRHR30-6P-6P(31)

Detailed Description

The HR30-6P-6P(31) connector, part of the HR30 series, is a high-performance component designed for reliable signal transmission in demanding environments. With a durable plastic housing and gold-plated contacts, it ensures optimal conductivity and corrosion resistance. Featuring a panel mount configuration and solder termination method, installation is secure and straightforward. This connector is built to withstand a wide temperature range from -25°C to 85°C and boasts an impressive IPX8 rating for ingress protection. Its straight mount angle and silicone rubber and chloroprene seals provide additional durability. With a shell size of 6 and a mating type of push-pull, it offers convenience and efficiency in mating cycles. RoHS compliant and suitable for use in hi-rel applications, the HR30-6P-6P(31) is a versatile solution for various circular connector needs.
