| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Hirose |
| Manufacturer Part Number: | Hirose HR34B-12WPK-10S |
| Series: | HR34B |
| Gender: | Female |
| Housing Material: | Metal |
| Number of Contacts: | 10 |
| Mount Type: | Panel Mount |
| Termination Method: | Solder |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -20 °C |
| IP Rating: | IP68 |
| Shell Size: | 12 |
| Mating Type: | Bayonet |
| Mount Angle: | Straight |
| Seal Material: | Fluoro Rubber, Nitrile Hydride Rubber |
| Shell Size - Insert Arrangement: | 12-10 |
| Mating Cycles: | 500 cycle |
| Wire Size: | 8 - 9 mm |
| Shell Finish: | Chrome |
| Current Rating: | 3 A |
| Voltage Rating: | 200 VAC |
| SKU: | HIRHR34B-12WPK-10S |
HR34B-12WPK-10S
| Heilind Number: | HIRHR34B-12WPK-10S |
| Manufacturer: | Hirose |
| Manufacturer Number: | HR34B-12WPK-10S |
| ECAD Model: | |
Specifications
Detailed Description
Introducing the HR34B-12WPK-10S, a rugged and reliable female circular connector designed for demanding environments. Crafted from durable metal housing with a sleek chrome finish, this connector ensures secure panel mounting with its straight bayonet mount angle. Featuring 10 gold-plated contacts, it guarantees excellent conductivity even in harsh conditions, with a current rating of 3A and a voltage rating of 200VAC. With an IP68 rating, it offers protection against dust and water ingress, while its wide operating temperature range of -20°C to 125°C makes it suitable for a variety of applications. The HR34B-12WPK-10S is RoHS compliant and engineered for 500 mating cycles, providing long-lasting performance. Perfect for industrial, aerospace, and military use, this connector, part of the HR34B series, is a dependable solution for your connectivity needs.
Product Change Notice
| Effective Date | Description of Change | Download | |||
|---|---|---|---|---|---|
| 03/31/2026 | PCN2025-09 - End of Life Some with replacement. [Material Change] For the HR10A series, the material of the bushing component will be changed. For the HR34B series, the coating material for the connection ring, connection sleeve, or shell will be changed. Please refer to Attachment 2 for details. There will be no differences in product performance, appearance, or color due to these changes. These changes will not affect the performances of the product. [Discontinuation of Sales] Due to decreased demand and difficulty in finding alternatives, we have decided to discontinue sales. | Download | |||
| 02/11/2022 | HIR-430-021018 - UL Clarification. Recently, Toray Industries, Inc.,(Hereinafter Toray) announced that certain resin products were improperly identified by Toray as receiving certification from Underwriters Laboratories (hereinafter, "UL"). | Download | |||
