RM15WTPZ-10S(81)

HIRRM15WTPZ-10S(81)
Heilind Number:HIRRM15WTPZ-10S(81)
Manufacturer:Hirose
Manufacturer Number:RM15WTPZ-10S(81)
ECAD Model:
3D Model

Specifications

AttributeValue
Product Category:
Circular Connectors & Accessories Circular Connectors
Manufacturer:Hirose
Manufacturer Part Number:Hirose RM15WTPZ-10S(81)
Series:RM-W
Gender:Female
Housing Material:Metal
Number of Contacts:10
Mount Type:Cable Mount
Termination Method:Solder
Contact Plating:Silver
Maximum Operating Temperature:85 °C
Minimum Operating Temperature:-25 °C
IP Rating:IPX8
Shell Size:15
Mating Type:Screw
Mount Angle:Straight
Seal Material:Silicone Rubber
Shell Size - Insert Arrangement:15-10
Mating Cycles:2000 cycle
Shell Finish:Chrome
Current Rating:5 A
Voltage Rating:350 VAC
SKU:HIRRM15WTPZ-10S(81)

Detailed Description

The RM15WTPZ-10S(81) is a high-performance circular connector from the RM-W series designed specifically for female gender applications. With a durable metal housing and IPX8 rating, this connector ensures reliable operation in demanding environments. Featuring 10 silver-plated contacts for optimal conductivity, it guarantees secure and efficient data and power transmission. The cable mount and straight mounting angle offer versatile installation options, while the silicone rubber seal provides excellent protection against moisture and dust. With a wide operating temperature range of -25°C to 85°C and a mating cycle of 2000, this connector is built to withstand harsh conditions. Ideal for a variety of industrial and commercial applications, the RM15WTPZ-10S(81) is a dependable solution for connectivity needs.
