ZE05-4P-2H(A)

HIRZE05-4P-2H(A)
Heilind Number:HIRZE05-4P-2H(A)
Manufacturer:Hirose
Manufacturer Number:ZE05-4P-2H(A)
ECAD Model:
3D Model

Specifications

AttributeValue
Product Category:
Automotive Connectors & Accessories Automotive Connectors
Manufacturer:Hirose
Manufacturer Part Number:Hirose ZE05-4P-2H(A)
Color:Gray
Pitch:2 mm
Gender:Female
Series:ZE05
Mount Type:Surface Mount, Through Hole
Mount Angle:Right Angle
Mating Cycles:30 cycle
Current Rating:2 A
Voltage Rating:60 V
Contact Plating:Tin
Housing Material:Nylon
Number of Contacts:4
Termination Method:Solder
Maximum Operating Temperature:125 °C
Minimum Operating Temperature:-40 °C
SKU:HIRZE05-4P-2H(A)

Detailed Description

Introducing the ZE05 Gray Female Automotive Connector ( ZE05-4P-2H(A)), a reliable solution for your surface mount and through hole connectivity needs. Crafted with durable nylon housing and featuring four tin-plated contacts, this connector ensures secure and efficient solder termination. With a wide operating temperature range of -40°C to 125°C, it is perfect for automotive applications. The 2mm pitch and right-angle mount design offer flexibility in installation. ROHS compliant and rated for 60V voltage and 2A current, this connector guarantees safe and high-performance operation. Whether you're working on automotive projects or general electronics, the ZE05 series delivers quality and durability.
