ZX80-B-5P(30)

HIRZX80-B-5P(30)
Heilind Number:HIRZX80-B-5P(30)
Manufacturer:Hirose
Manufacturer Number:ZX80-B-5P(30)
ECAD Model:
3D Model

Description:

242-0051-0-30 EACH

More >>

Specifications

AttributeValue
Product Category:
IO Connectors USB Connectors
Manufacturer:Hirose
Manufacturer Part Number:Hirose ZX80-B-5P(30)
Color:Black
Gender:Female
Series:ZX
Mount Type:Surface Mount
Mount Angle:Straight
USB Standard:USB 2.0
Mating Cycles:10000 cycle
Current Rating:1.8 A
Voltage Rating:30 VAC
Number of Decks:Single Deck
Number of Ports:1
Contact Material:Copper Alloy
Housing Material:Liquid Crystal Polymer
Termination Method:Solder
Flammability Rating:UL 94V-0
Maximum Operating Temperature:85 °C
Minimum Operating Temperature:-30 °C
SKU:HIRZX80-B-5P(30)

Detailed Description

Introducing the ZX80-B-5P(30) USB connector, a sleek and durable solution for seamless data transfer in electronic devices. Designed for female gender applications, this connector boasts a black color and is part of the ZX series. Crafted with Liquid Crystal Polymer housing material and featuring a surface mount design with solder termination, it ensures secure and reliable connectivity. With a maximum operating temperature of 85°C and a minimum of -30°C, it guarantees consistent performance even in challenging environments. Its straight mount angle and single port configuration make installation a breeze. Each connector is rated for 10,000 mating cycles and complies with RoHS standards for environmentally friendly manufacturing. With a current rating of 1.8A and voltage rating of 30VAC, it is perfect for USB 2.0 applications. The ZX80-B-5P(30) is your go-to choice for high-quality USB connectivity.
