| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09022326835 |
| Color: | Pebble Gray |
| Series: | DIN 41612 |
| Gender: | Female |
| Housing Material: | Glass-Filled Plastic |
| Number of Contacts: | 32 |
| Number of Rows: | 1 |
| Termination Method: | Solder |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| Mount Angle: | Straight |
| Tail Length: | 4.5 mm |
| Mating Cycles: | 400 cycle |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 2 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09022326835 |
09022326835
Specifications
Detailed Description
Introducing the DIN-SIGNAL B032FS-4 5C1-2, a high-quality female connector from the renowned DIN 41612 series. Crafted from durable glass-filled plastic in a sleek Pebble Gray hue, this connector features 32 contacts in a single row, perfect for seamless board-to-board PCB connections. With a solder termination method and copper alloy contacts plated with tin over nickel and noble metal, it ensures reliable performance even in extreme temperatures ranging from -55°C to 125°C. Designed for straight mount angles with a 2.54mm pitch and 4.5mm tail length, it offers easy installation and secure connectivity. With a UL 94V-0 flammability rating and RoHS compliance, it guarantees safety and environmental responsibility. With a 1kV voltage rating and 2A current rating, it is suitable for a wide range of applications. Trust in the 09022326835 for superior quality and performance in your connectivity needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
