| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09032646861 |
| Color: | Pebble Gray |
| Series: | DIN 41612 |
| Gender: | Female |
| Housing Material: | Glass-Filled Plastic |
| Number of Contacts: | 64 |
| Number of Rows: | 3 |
| Termination Method: | Press-Fit |
| Contact Material: | Copper Alloy |
| Contact Plating: | Nickel, Noble Metal Over Nickel |
| Maximum Operating Temperature: | 105 °C |
| Minimum Operating Temperature: | -40 °C |
| Pitch: | 2.54 mm |
| Mount Angle: | Straight |
| Tail Length: | 13 mm |
| Mating Cycles: | 400 cycle |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 2 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09032646861 |
09032646861
Specifications
Detailed Description
Introducing the 09032646861, a DIN 41612 Type C Connector designed for seamless connectivity in electronic systems. This Female connector, constructed with durable thermoplastic resin and glass-fibre fill, ensures reliable performance. With 64 contacts arranged in 3 rows, it facilitates high-density PCB connections. The Press-Fit termination method offers easy and secure installation, ideal for Motherboard to daughtercard and Mezzanine applications. Featuring a Pebble Gray housing and straight mount angle, it blends functionality with sleek design. With a wide operating temperature range from -40°C to 105°C, it guarantees stable operation in various environments. RoHS compliant and boasting a voltage rating of 1kV, this connector prioritizes both performance and environmental responsibility. Trust the 09032646861 for your critical board-to-board interconnect needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
