| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09033322921 |
| Color: | Pebble Gray |
| Pitch: | 2.54 mm |
| Gender: | Male |
| Series: | DIN 41612 |
| Mount Angle: | Right Angle |
| Mating Cycles: | 500 cycle |
| Current Rating: | 2 A |
| Number of Rows: | 3 |
| Voltage Rating: | 1 kV |
| Contact Plating: | Gold Over Electroless Nickel Phosphorus Over Nickel, Tin Over Nickel |
| Contact Material: | Copper Alloy |
| Housing Material: | Glass-Filled Plastic |
| Number of Contacts: | 32 |
| Termination Method: | Solder |
| Flammability Rating: | UL 94V-0 |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | HRT09033322921 |
09033322921
Specifications
Detailed Description
Introducing the 09033322921, a high-performance DIN 41612 Type C male connector designed for seamless motherboard to daughtercard, extender card, and PCB to cable connections. Constructed from durable thermoplastic resin with glass-fibre filling in a sleek Pebble Gray hue, this connector ensures reliable performance in various applications. Featuring 32 contacts in 3 rows, each made of copper alloy with tin plating for optimal conductivity. With a wide operating temperature range of -55°C to 125°C, it guarantees stability even in extreme conditions. The solder termination method and right-angle mount angle provide easy installation on PCBs. UL 94V-0 rated for superior safety, with a current rating of 2A and voltage rating of 1kV, meeting stringent industry standards. With a lifespan of 500 mating cycles, this DIN 41612 connector is a dependable choice for board-to-board and board stacking connections.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
