09110006161

HRT09110006161
Heilind Number:HRT09110006161
Manufacturer:HARTING
Manufacturer Number:09110006161
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

HARTING offers a large range of terminations technology for contacts: - Screw terminal - Crimp terminal - Axial screw terminal - Cage-clamp terminal - IDC (Insulation displacement terminal) - Han-Quick Lock® termination technique

More >>

Specifications

AttributeValue
Product Category:
Crimp Wire Housings & Contacts Crimp Wire Contacts
Manufacturer:HARTING
Manufacturer Part Number:HARTING 09110006161
Series:TC 650
Gender:Male
Termination Method:Crimp
Contact Material:Copper Alloy
Contact Plating:Silver
Maximum Operating Temperature:125 °C
Minimum Operating Temperature:-40 °C
Contact Resistance:0.3 mOhm
Mating Cycles:500 cycle
Wire Size:70 mm²
Contact Design:Machined
Current Rating:650 A
Stripping Length:42 mm
SKU:HRT09110006161

Detailed Description

Introducing the HARTING TC 650 Crimp Contact, a high-performance termination technology for male connectors. Designed for use with 70 mm² wire, this contact features a durable Copper Alloy construction with Silver plating for optimal conductivity. With a current rating of 650 A and a low contact resistance of 0.3 mOhm, it ensures reliable power transmission in demanding applications. The machined contact design guarantees precision and longevity, with a maximum operating temperature of 125 °C and RoHS compliance for environmental responsibility. Perfect for industrial settings, this Crimp Contact is suitable for 500 mating cycles, offering durability and performance you can trust. Upgrade your connectivity with the HARTING TC 650 Crimp Contact, part number 09110006161.
