09110006240

HRT09110006240
Heilind Number:HRT09110006240
Manufacturer:HARTING
Manufacturer Number:09110006240
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

HARTING offers a large range of terminations technology for contacts: - Screw terminal - Crimp terminal - Axial screw terminal - Cage-clamp terminal - IDC (Insulation displacement terminal) - Han-Quick Lock® termination technique

More >>

Specifications

AttributeValue
Product Category:
Crimp Wire Housings & Contacts Crimp Wire Contacts
Manufacturer:HARTING
Manufacturer Part Number:HARTING 09110006240
Series:TC 350
Gender:Female
Termination Method:Crimp
Contact Material:Copper Alloy
Contact Plating:Silver
Maximum Operating Temperature:125 °C
Minimum Operating Temperature:-40 °C
Contact Resistance:0.3 mOhm
Mating Cycles:500 cycle
Wire Size:35 mm²
Contact Design:Machined
Current Rating:350 A
Stripping Length:26 mm
SKU:HRT09110006240

Detailed Description

Introducing the HARTING TC 350 series crimp contact, designed for reliable and efficient termination in high-power applications. This female contact, featuring a wire size of 35 mm², is ideal for use with heavy-duty cables. Crafted from copper alloy with silver plating, it ensures optimal conductivity and corrosion resistance. The machined contact design guarantees precision and durability, while the crimp termination method simplifies installation. With a current rating of 350 A and a low contact resistance of 0.3 mOhm, this contact offers superior performance. RoHS compliant and capable of withstanding temperatures ranging from -40 °C to 125 °C, it is suitable for a wide range of industrial environments. Trust in the HARTING TC 350 for secure and long-lasting connections in your power systems.
