| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185066814 |
| Series: | SEK |
| Gender: | Female |
| Housing Material: | Plastic |
| Number of Contacts: | 6 |
| Number of Rows: | 2 |
| Termination Method: | IDC |
| Contact Material: | Copper Alloy |
| Contact Plating: | Gold Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 1.27 mm, 2.54 mm |
| Housing Color: | Gray |
| Mating Cycles: | 250 cycle |
| Wire Size: | 28 - 26 AWG |
| Performance Level: | Class II |
| Current Rating: | 2.5 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09185066814 |
09185066814
Specifications
Detailed Description
Introducing the SEK Female Connector with Closed End Cover, the ideal solution for secure and reliable cable connections. This high-performance connector, part of the SEK series, features a durable thermoplastic resin (PBT) construction in a sleek beige hue. With 6 contacts and a 2.5A rated current, it ensures efficient power transmission. The IDC termination method, along with gold over nickel and tin over nickel contact plating, guarantees impeccable conductivity. Operating between -55°C to 125°C, this connector is suitable for a wide range of environments. RoHS compliant and with a voltage rating of 1 kV, it meets international quality standards. Perfect for FFC, FPC, and IDC ribbon cable applications, the SEK Female Connector is a must-have for your connectivity needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
