| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185066926 |
| Color: | Gray |
| Series: | SEK Standard |
| Housing Material: | Plastic |
| Number of Contacts: | 6 |
| Number of Rows: | 2 |
| Termination Method: | Wire Wrap |
| Contact Material: | Copper Alloy |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| Pitch: | 2.54 mm |
| IP Rating: | IP20 |
| Mount Angle: | Right Angle |
| Tail Length: | 15 mm |
| Flammability Rating: | UL 94V-0 |
| Current Rating: | 1 A |
| Voltage Rating: | 1 kV |
| SKU: | HRT09185066926 |
09185066926
Specifications
Detailed Description
Introducing the SEK Standard Male Connector, a versatile and reliable component for your electronic assembly needs. Constructed with high-quality thermoplastic resin (PBT) in a sleek beige hue, this connector is designed for seamless PCB to cable connections. With a wrap termination method and six copper alloy contacts, it ensures secure and efficient transmission of signals. Its angled configuration and right-angle mount make it perfect for space-saving installations. Rated for a current of 1A and a voltage of 1kV, it guarantees optimal performance even in demanding environments. With a wide operating temperature range from -55°C to 125°C and a UL 94V-0 flammability rating, it offers durability and safety. Trust in the SEK Standard Male Connector for your connectivity solutions.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
